Market-Leading Technology Solutions
System solutions for any drillhole survey applications
XTrak best in class technology provides customers with technological solutions to improve productivity, balancing simplification with functionality, reducing operating expenditure and generating sustainable outcomes and benefits.
The XTrak product range is synonymous with high performance, reliability, accuracy, and ease of use.
GyroTrak AQ Driller Operated Gyro System
The world's smallest north-seeking all angle solid state gyro
The GYROTRAK gyro instrument is the ultimate gyro survey instrument. It is the worlds smallest northseeking gyro instrument (AQ), designed to meet the vigorous requirements of the mining and minerals exploration drilling market. Part of the XTrak family of drilling tools, the GyroTrak tool offers all angle northseeking, high speed continuous, overshot and blast hole survey capability. The GyroTrak uses the latest MEMS sensor technology for accuracy and reliability.
Capabilities:
-
High Accuracy North Seeking
-
All angle NS survey capability in AQ size
-
USB re-chargeable battery.
-
High speed continuous - all angle capability.
-
Blast hole and Overshot survey capable
.
RigTrak Rig Alignment System
The most compact easy to use high accuracy rig alignment system
The RIGTRAK gyro rig alignment system is an innovation in rig alignment. This compact high accuracy survey instrument enables fast and flexible alignment of a drill rig whether on surface or underground. Part of the XTrak family of drilling tools, the RigTrak offers the most flexible solution on the market today. Initial alignment can be established on or off the rig and takes and is fast. The system is also lightweight and easy to use and provides extra long battery life.
Capabilities:
-
High Accuracy North Seeking rig alignment
-
All angle survey alignment capability
-
USB re-chargeable long life battery.
-
Fast alignment on or off rig .
-
Lightweight with no export restriction
CoreTrak Core Orientation Module
The world's easiest to use Core Orientation tool
The CORETRAK instrument is an innovation in Core Orientation while drilling. It is an integrated Core orientation module designed to survive the vigours of the coring environment. It provides measurement whilst core drilling and is very easy to use. Part of the XTrak family of drilling tools, the CoreTrak tool offers surveys while Core drilling, as well as regular Core orientation. The CoreTrak uses the latest MEMS sensor technology for accuracy and reliability.
Capabilities:
-
Measurement While Core Drilling
-
Extended battery life, USB re-chargeable.
-
Compatible with standard Core barrel assemblies
OSTrak Overshot Survey System
The worlds first integrated northseeking overshot survey tool
The OSTRAK gyro instrument is an innovation in overshot survey capability. It is compact gyro module with built in northseeking capability, used as part of the overshot assembly. Designed to survive the vigours of the coring environment, it provides fast northseek surveys before retrieval of the core barrel and eliminates the need for additional instruments and running gear. Part of the XTrak family of drilling tools, the OSTrak tool offers northseeking directional surveys at the end Core drilling with no impact on drilling operations. The OSTrak uses the latest MEMS sensor technology for accuracy and reliability.
Capabilities:
-
High Accuracy North Seeking
-
Measurement before retrieving Core Barrel
-
Extended battery life, USB re-chargeable.
-
Compact design, easy to use.
-
Fast to use with little impact on operations
-
Backend compatible
FastTrak Slimhole Continuous Gyro System
High accuracy, high speed continuous gyro survey instrument
The FASTTRAK gyro instrument is a slimhole gyro instrument, designed to meet the vigorous requirements of the mining and minerals exploration drilling market. Part of the XTrak family of drilling tools, the FastTrak tool offers all angle, high speed continuous surveys. The FastTrak uses the latest MEMS sensor technology for accuracy and reliability.
Capabilities:
-
High Accuracy with no running restrictions
-
All angle continuous survey capability
-
USB re-chargeable battery.
-
High speed continuous - all angle capability.
-
Overshot survey capable
GammaTrak Slimhole Gamma Logging System
High sensitivity continuous gamma radiation measurement
The GAMMATRAK instument is a slimhole natural gamma instrument, designed to meet the requirements of the mining and minerals exploration drilling market. Part of the new Xtrak family of drilling tools, the GammaTrak tool offers continuous drillhole background gamma radiation measurement capability, as an add on service to any of the XTrak downhole systems..The GammaTrak uses high performance, rugged sensor technology for accuracy and reliability. It seamlessly integrates with the DepthTrak system and DrillTrak cloud storage facility.
Capabilities:
-
High sensitivity with flexible running configurations
-
API calibrated data log
-
USB re-chargeable battery.
-
Continuous logging capability.
-
High capacity memory for extended run time
DepthTrak Wireline Depth Measurement System
High resolution wireless depth measurement system
The DEPTHTRAK system is a wireless depth measurement system, which attaches to the drill pipe and measures wireline depth when running continuous surveys or logs in a drillhole. Connected to a tablet via a relaible blue tooth link, it is designed to meet the demanding requirements of the mining and minerals exploration drilling market. Part of the XTrak family of drilling tools, the DepthTrak system offers continuous wireline measurement capability, when run in conjunction with any of our drillhole survey systems The DepthTrak counter is unique in the industry as it does not require regular charging and provides continuous operational use for over a year. DepthTrak uses high performance, rugged sensor technology for accuracy and reliability. It seamlessly integrates with the GyroTrak and GammaTrak systems.
Capabilities:
-
High resolution wireless depth measurement
-
Long life battery avoids need for recharge (12 month battery life)
-
Low maintenance, compact, safe and easy to use
-
Continuous logging capability.
-
Integrates with XTrak drillhole systems
DrillTrak Software Suite and Cloud Storage for XTrak Systems
DrillTrak offer a multiplatform user interface for the Xtrak tools and includes seemless cloud storage
The DRIILLTRAK software suite is an easy to use software support package for the XTrak range of instruments. It provides a seamless cloud based storage solution for all XTrak products, enabling easy access to suvey information and flexible data reporting. It also provides data export capability to industry standard cloud repositories. It also provides a data audit capability and remote monitoring of data quality to improve data accuracy and reliability.
Capabilities:
-
Software support for all XTrak systems
-
Seamless Cloud data storage
-
Remote data access and reporting
-
Data audit and quality control
-
Compatible with industry standard data repositories
MagTrak Magnetic mulishot survey system
The Magtrak sets the benchmark for magnetic multishot instruments
The MAGTRAK magnetic survey instrument is a slimhole magnetic multishot instrument. It is designed to meet the vigorous requirements of the mining and minerals exploration drilling market. Part of the XTrak family of drilling tools, the MagTrak tool offers e survey capability down to BQ and blast hole . The MagTrak uses the latest MEMS sensor technology for accuracy and reliability.
Capabilities:
-
High Accuracy
-
USB re-chargeable battery – extended run time
-
High reliability
-
Multishot and Blast hole survey capable
